Pizza is built around 3 internal oscillators - the Main Oscillator, which can be phase modulated (FM) and wave folded, and two modulating oscillators. The modulating oscillators are the Octave (sub) Oscillator, with dedicated output, and the Ratio Oscillator, serving more advanced FM duties. Both have square-sine-saw wave shape control for more timbral variety and can ring modulate the main oscillator.
GENERAL FEATURES
Complex oscillator with 3 internal oscillators
Main Oscillator with phase modulation (FM), wave folding, and ring modulation
Octave Oscillator with independent output, square-sine-saw waveshaper, and independent output
Ratio Oscillator for FM with user-adjustable ratios and square-sine-saw waveshaper
3 waveform outputs
Pulse output of the Main Oscillator
FM Index crossfader between Ratio Oscillator and Octave Oscillator
Index Mod attenuverter for the dedicated CV input
SHAPE section with wave-shaping of operators, 2 flavors of wave-folding, and ring modulation
Sync input to reset all oscillators
Octave transposition and detune via Pitch knob
Tune mode for adjusting semitone transposition and fine-tune
EXT input to replace phase modulation of the Octave Oscillator with external signal
V/OCT input with automatic calibration and quantization
